The transformer core is made of high – tech material base on nanotechnology. |
|
The Tri-proof (water, dust and eroding proof) cooling system raises the reliability and duty cycle of the key components. |
|
Suitable fan is provided for adequate cooling of the system. |
|
With OCV as high as 70V enables the machine to weld acid and basic electrodes. The output cables (50sqmm.) will be able to be extended to 150M. |
|
With independent adjustment for hot – start current enables usage of different electrode without any additional setting. |
|
The duty cycle is higher than 60% when the temperature of the operation surrounding is around 40ºC. |
|
The maximum output efficiency is 93%. By using the advanced electro – circuit for power factor compensation, the max power factor could be as high as 0.95. |
|
EMC electro – circuit added to reduce the pollution to the electric network. |
|
With digital display of the welding current and remote control for option. |
