WELDING MACHINE TIG
	Ref : 015692 GYSMI TIG 180 HF AC/DC • Inverter based • Energy efficient • Light weight • User friendly Tig machine MMA -Tig- 230 V DC-AC-10-180 A. (TIG : 80% 120A)

TIG 180 <HF> AC/DC is designed to weld Aluminum, Steel, Inox Single phase 230 V

TIG FUNCTION

A) AC Mode (Aluminium)
Adjustment of the balance for the cleaning / penentration 20% -> 60%

Adjustment of frequency for arc accuracy : 20 200 HZ
Manual
Automatic

B) Common Options (AC and DC Mode)

2 Possibilities of starting up
HF without contact
Lift (TSL) with contact . GYS process

Pulse mode
Ticking off mode : position spot for welding
2T / 4 T Function
Pre - gas and progressive current increase : pre adjusted
Downslope and post-gas adjustable

MMA FUNCTION

Electrodes 1, 6 to 4 mm
ARC Force
HOT Start
Anti sticking

OTHER SPECIFICATIONS

Protection for power generator (+/- 15%)
Main supply lead : 1 m80
TIG 180 HF AC/CD + accessories (ref : 015661)
torch SR 17,4 m (pawl with trigger)

Tube and pressure reducers cables with electrodes holder and earth clamp for MMA
